Linux NAS | SMB - Tower

N5200XXX Expand Your Data, Expand Your Reach
  • Extreme Speed
  • Extreme Data Backup
  • Extreme Power Management
  • Extreme Protection
  • iSCSI Thin Provisioning Support
  • Online RAID Volume Management


Awards/Reviews

2013-02-13
Media: AVR Magazine | Country: Italy

“This NAS is of excellent quality and is offered at an affordable price in my opinion. It can be used for both at home and for those who have a small business and need a constant and great support for storing their data.”

2012-04-23
Media: Chip Magazine India | Country: India

“If you are in need of an enterprise level network storage drive for small office or a large networked home, the Thecus® N5200XXX should be on your list.”

2012-04-12
Media: XtremeHardware | Country: Italy

“considering the performance offered by the Intel® Atom™ processor, it deserves our Best Buy for the ward's best price/performance.”

2012-02-27
Media: Tweak.dk | Country: Denmark

“It provides some really good download speeds and can be installed up to 15TB storage capacity, which is incredibly nice.”

2012-01-02
Media: ComputerDIY | Country: Taiwan

"In most people's computers, data is not backed up to a server or cloud service, but rather put on a flash drive in case of a crash. For information users forgot to back up, there's nothing they can do but cry. With iSCSI, users can easily use remote storage as virtual local hard drives, letting users keep the backup data methods that they're used to. Using a NAS's RAID functionality can let users have even more data protection so they don't need to fear that if their computer crashes, their data will follow."

Features

  • Extreme Speed
    With a power-house of a processor in the Intel Atom D525 running at 1.8GHz, the N5200XXX runs circles around the competition. Combined with 1GB of super fast DDR3 RAM, that means incredible transfer speeds and less time spent waiting.
  • Extreme Data Backup
    Secure your data with the sophisticated features and refined simplicity that only Thecus can offer. Incremental backups and recover data with Acronis’s True Image software, take and revert back to system snapshots at your leisure, and remotely backup to anywhere in the world with native Rsync support.
  • Extreme Power Management
    N5200XXX supports scheduled power on/off. With this feature, users can set what time the system turns on or off. This feature is a big plus for people who want to conserve energy. Wake-On-LAN enables users to remotely turn the system on without leaving their seat.
  • Extreme Protection
    Put safety first with AES256bit RAID volume encryption and USB Key functionality. An impenetrable wall of protection is at your disposal to make sure only those you want can access your data, and no one else. Simply set up a USB flash drive key that unlocks your data with no hassle and maximum protection.
  • iSCSI Thin Provisioning Support
    Get the most out of your storage space with the extreme speed of iSCSI and the efficiency of iSCSI thin provisioning. Connect through iSCSI for the fastest data transfer speeds available and make wasted disk space a thing of the past with thin provisioning's flexible storage functionality.
  • Online RAID Volume Management
    Managing RAID volumes has never been easier thanks to the N5200XXX's Online RAID Volume Management. Administrators can easily expand or migrate RAID volumes without having to power down the system, eliminating costly downtime.

Overview

The new XXX line of Thecus NAS is leading the way in catering to your needs. With Xtreme power, Xtreme function, and Xtreme value, these Thecus NAS deliver. Whether it be a strong product for a budget price or a high-powered NAS for the tech-savvy, each model is extremely geared towards fitting you. From an extremely speedy 2-bay for your home office to an extremely powerful 8-bay rackmount for even the most demanding enterprise, Thecus XXX NAS are ready for you.

With the pace of technological improvement accelerating every day, it is essential for products to have staying power. Data capacity and storage needs are expanding quickly and your NAS needs to be able to adjust to your future. The N5200XXX is capable of storing up to 15TB of data, which gives you all the capacity you will need for many years to come. This NAS is perfect for small and medium businesses with increasing data storage needs, as well as private web experts running web services such as FTP sites, web sites, or sharing hubs.

5 bays with 15TB of data capacity can supply businesses with serious data needs, but also provides flexibility for those with less extreme demands. With 5 bays available, it is easy to get started with 2 or 3 disks (that’s still 6 or 9TB’s of storage!) and add more disks as your needs increase. Libraries grow, files get larger, businesses develop; there are many reasons to allow yourself room to expand in the future. The extra bays can also house inactive spare disks that will automatically be activated as soon as they are needed. People from all walks of life are beginning to realize the value that NAS can give them and flexibility is extremely important.

Having sufficient data capacity and expandability are extremely valuable, but it is equally important to have a NAS with speed that will pass the test of time. The N5200XXX runs the latest generation of Atom processors, the Intel Atom D525, and has a formidable 1GB of DDR3 memory. This makes it powerful enough to host hundreds of users, perform massive uploading and downloading operations with great speed, and run many functions simultaneously. The N5200XXX is a great solution for anyone in search of a long-term solution with expanding data needs.

Specs

1.Hardware Platform
Item Spec
Processor Intel® Atom™ D525
System Memory 1 GB DDR3 SODIMM
LAN Interface RJ-45x2 : 10/100/1000 BASE-TX Auto MDI/MDI-X
USB Interface USB 2.0 host port x5 (Front x1, Back x4) (A Type)
LED indicator Power(Blue)
System Status : Busy (FW Upgrade)(Orange)
HDD1-5 Activity/Fail(Orange/Red)
WAN/LAN1 (Link : Green; Activity : Orange)
LAN2 (Link : Green; Activity : Orange)
USB (Copy LED: Blue)
Disk interface 5 x SATA for internal
1x eSATA for external
Power 200W Power Supply
Thermal Thermal sensor on processor temperature
Real-time clock Battery backup system clock
Power management Power on after power lose resume
Buzzer Frequency Controllable
Buttons Power button
LCM button (ENT,ESC,UP, DOWN)
Environment Temperature : 5°C to 40°C
Humidity : 0 ~ 80 % R.H. (Non-condensing)
Dimension Tower Base

2. Software Functions
RAID
RAID modes RAID 0, 1, 5, 6, 10 and JBOD
Auto-rebuild Supported
Hot-swap Supported
Hot Spare Supported
On line RAID Migration Supported
On line RAID Expansion Supported
RAID Volume Encryption AES256bit
Disk
Power management Spin down while idle time setup
Bad Block Scan Supported
SMART Info Supported
SMART Test Supported
Roaming Supports roaming to other N5200XXX
Network
Configuration Fixed IP Address, Dynamic IP Address
IP sharing mode Can be enable/disabled
Transport Protocols TCP/IP/Appletalk
File Protocols SMB/CIFS, HTTP/HTTPS, FTP, TFTP, NFS v3, AFP
Link Aggregation Local balance, Failover, Balance-XOR, 802.3ad, Balance-TLB, Balance-ALB
Data Access
Client OS support Windows XP and after
Windows Server 2003 and after
UNIX/Linux
Mac OS X
WebDisk Web-based file access
TFTP Build in TFTP Server
FTP Build in FTP Server with bandwidth control
Secure FTP Build in secure FTP Server with  bandwidth control
Download Manager (Module) HTTP / FTP / BT / eMule / NZB
Printer Server (IPP) Supports USB printers
Supports IPP various printers
Client can manage print tasks  (List/Delete) via Web user interface
Data Backup
Client incremental data backup Acronis True Image (OEM)
Client system Disaster Recovery Acronis True Image (OEM)
USB device copy to N5200XXX Through LCM to control
Snapshot Supported
Bi-directional USB Copy (Module) Supported
Native Rsync Supported
Block Level Access
iSCSI Target/Initiator Supports Microsoft/Mac OS X/Linux initiators and Thecus NAS targets
iSCSI Thin Provisioning Configurable to virtual size as system allowed capacity
Power management
Schedule power on/off Supported
Volume management
Multiple file system selectable EXT3 / EXT4 / XFS / ZFS
Multiple RAID Supported
Multimedia Support
iTunes Server Supports AAC, MP3 w/ ID3 tag and WAV
Photo Web Server (Piczza!™ module) Supports GIF, JPG (JPEG) and PNG
Supports EXIF display
Supports slide show
Media server Supports uPnP AV streaming protocol
User Authentication
Local User Supports built-in user accounts
Local Group Supports built-in user groups
Windows NT/ADS Supported
File System
Type Journaling File System
Capacity 16TB (XFS,ZFS,EXT4) / 8TB (EXT3) per volume
Language Support Unicode Support
Authorization (ACL) Read, Write or Deny options on individual users or groups for share and sub-folders
User Quota Supported
Administration
Multi-Lingual Web-based administration Web-based server management Interface Supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian  Polish and Portugal
Utility Program MS Windows Setup Wizard,
Supports Windows 2000/XP/2003/Vista/7
Mac setup Wizard (OS X only)
Email notification Sends system messages via Email to system administrator
SNMP trap System information trap out
Others
Web Disk Supported
Dual DOM Supported
Recycled bin Supported
Web Server (Module) Supported
ISO Mount Supported
User module Supported
IP CAM surveillance (Module) Supports up to 5 IP CAM
USB/eSATA schedule backup (Module) Supported
RAID replication (Module) Supported
Mail server (Module) Supported

Package Contents

Accessory Bag(with key) Ethernet Cable Power Cord Acronis True Image DVD
Universal CD QIG Warranty Card HDD Compatibility List Card
